面向110KV电压等级的电力变换应用。现有样本提供相应容量、额定电压、分接范围、联结组别、空载电流及阻抗等参考数据,并区分有载及无励磁调压结构。选型时应明确所需绕组数量、系统电压、负载和安装条件。具体损耗、试验及附件配置以项目技术协议为准。
Oil free, with strong fire resistance, eliminating the risk of oil leakage; Capable of withstanding short-circuit current and overvoltage, and adapting to harsh environments.
Using environmentally friendly materials, low noise and no pollution, to assist in the construction of a green power grid.
Efficient cooling system ensures that the equipment maintains low temperature during long-term operation, effectively extending the service life of the equipment.
Humanized design, simple operation, convenient and fast daily inspection and maintenance, significantly reducing operating costs.
Durable shell design, impact resistance, corrosion resistance, able to adapt to various complex and harsh working environments.
Modular structure design, supporting quick disassembly and assembly, combined with intelligent monitoring system, making operation and maintenance work more worry free and effortless.
110KV 油浸式三相双绕组无励磁调压电力变压器
额定容量 | 额定电压及分接范围 | 联结组别 | 空载电流 | 阻抗电压 | 空载损耗 | 负载损耗 | ||
高压 | 分接范围(%) | 低压 | ||||||
6300 | 110/115/121 | ±2×2.5 | 6.3/6.6/10.5 | YNd11 | 0.5 | 10.5 | 4.1 | 32 |
8000 | 0.5 | 4.9 | 38 | |||||
10000 | 0.46 | 5.8 | 45 | |||||
12500 | 0.46 | 6.8 | 53 | |||||
16000 | 0.43 | 8.3 | 65.7 | |||||
20000 | 0.43 | 9.7 | 79 | |||||
25000 | 0.4 | 11.4 | 94 | |||||
31500 | 0.38 | 13.5 | 111 | |||||
40000 | 0.36 | 16.2 | 133 | |||||
50000 | 0.34 | 19.4 | 158 | |||||
63000 | 0.3 | 22.9 | 187 | |||||
75000 | 0.26 | 26 | 212 | |||||
90000 | 13.8/15.75/18/21 | 0.24 | 12-14 | 29.9 | 245 | |||
120000 | 0.22 | 37.3 | 303 | |||||
150000 | 0.19 | 44.1 | 359 | |||||
180000 | 0.16 | 49.5 | 411 | |||||
110KV 油浸式三相三绕组无励磁调压变压器
额定容量 | 额定电压及分接范围 | 联结组别 | 空载电流 | 短路阻抗(%) | 空载损耗 | 负载损耗 | ||||
高压 | 分接范围(%) | 中压 | 低压 | 升压 | 降压 | |||||
6300 | 110 | ±2×2.5 | 36 | 6.3 | YNyn0d11 | 0.53 | 高压~中压 | 高压~中压 | 4.9 | 40 |
8000 | 0.5 | 5.8 | 48 | |||||||
10000 | 0.47 | 6.9 | 56 | |||||||
12500 | 0.45 | 8.1 | 67 | |||||||
16000 | 0.42 | 9.8 | 81 | |||||||
20000 | 0.42 | 11.6 | 95 | |||||||
25000 | 0.38 | 13.5 | 113 | |||||||
31500 | 0.38 | 16.2 | 134 | |||||||
40000 | 0.35 | 19.1 | 161 | |||||||
50000 | 0.35 | 22.9 | 192 | |||||||
63000 | 0.32 | 27.1 | 230 | |||||||
110KV 油浸式三相双绕组有载调压电力变压器
额定容量 | 额定电压及分接范围 | 联结组别 | 空载电流 | 阻抗电压 | 空载损耗 | 负载损耗 | ||
高压 | 分接范围(%) | 低压 | ||||||
6300 | 110 | ±4×1.25 | 6.3 | YNd11 | 0.51 | 10.5 | 4.4 | 32 |
8000 | 0.51 | 5.3 | 38 | |||||
10000 | 0.47 | 6.2 | 45 | |||||
12500 | 0.47 | 7.4 | 53 | |||||
16000 | 0.44 | 8.9 | 66 | |||||
20000 | 0.44 | 10.6 | 79 | |||||
25000 | 0.41 | 12.5 | 94 | |||||
31500 | 0.41 | 14.9 | 111 | |||||
40000 | 0.37 | 17.8 | 140 | |||||
50000 | 0.37 | 10.5~18 | 21 | 175 | ||||
63000 | 0.34 | 25 | 209 | |||||
110KV 油浸式三相三绕组有载调压电力变压器
额定容量 | 额定电压及分接范围 | 联结组别 | 空载电流 | 阻抗电压 | 空载损耗 | 负载损耗 | |||
高压 | 分接范围(%) | 中压 | 低压 | ||||||
6300 | 110 | ±4×2.5 | 36 | 6.3 | YNyn0d11 | 0.61 | 高压~中压 | 5.3 | 40 |
8000 | 0.61 | 6.3 | 48 | ||||||
10000 | 0.57 | 7.5 | 56 | ||||||
12500 | 0.57 | 8.9 | 67 | ||||||
16000 | 0.54 | 10.6 | 81 | ||||||
20000 | 0.54 | 12.5 | 95 | ||||||
25000 | 0.5 | 14.9 | 113 | ||||||
31500 | 0.5 | 17.7 | 134 | ||||||
40000 | 0.46 | 21.2 | 161 | ||||||
50000 | 0.46 | 25 | 192 | ||||||
63000 | 0.42 | 29.8 | 230 | ||||||
